The Link 5 Bar MAP Sensor EU is designed for accurate manifold pressure readings in high-boost turbocharged and supercharged applications. Reading up to 5 Bar absolute pressure, it is suitable for engines running up to approximately 4 Bar, or around 58 PSI, of boost pressure.
This sensor includes the plug and pins for installation and is ideal for performance, motorsport, and high-boost ECU setups.
Key Features
- 5 Bar absolute pressure range
- Suitable for turbocharged and supercharged engines
- Supports up to approximately 4 Bar / 58 PSI of boost
- Includes plug and pins
- Compatible with Link G4, G4+, and G4X ECUs
- Ideal for high-boost performance applications
Connection Details
- Calibration: 0 kPa = 0.5V, 500 kPa = 4.5V
- Pin A: 0V
- Pin B: 5V
- Pin C: Signal
- Select “Variohm 5 Bar” as the MAP sensor type in PCLink
